Einzelheiten zum Produkt
Zertifizierung: ISO9001, CE, SGS TUV
Zahlungs- und Versandbedingungen
Modell Nr.: |
CAAI-Kabel mit vollständigem Leiter |
Form des Materials: |
Runddraht |
Benutzungsmöglichkeit: |
Unkosten |
Marke: |
UME |
Inspektion durch Dritte: |
Annahme |
Probe: |
frei |
Farbe: |
Kunde spezifiziert |
OEM-Produkte: |
Annahme |
Transportpaket: |
Schlagzeug |
Spezifikation: |
CAAI-Kabel mit vollständigem Leiter |
Handelsmarke: |
UME |
Ursprung: |
China |
Hs-Code: |
8544492100 |
Versorgungsmaterial-Fähigkeit: |
500, 000 km pro Monat |
Typ: |
Isoliert |
Typ des Leiters: |
Massivstrang |
Anwendung: |
Unkosten |
Leitermaterial: |
Aluminium |
Gehäusematerial: |
mit einer Breite von nicht mehr als 15 mm |
Isoliermaterial: |
xlpe |
Proben: |
US$ 1/Stück 1 Stück ((Min.Bestellung) |
Modell Nr.: |
CAAI-Kabel mit vollständigem Leiter |
Form des Materials: |
Runddraht |
Benutzungsmöglichkeit: |
Unkosten |
Marke: |
UME |
Inspektion durch Dritte: |
Annahme |
Probe: |
frei |
Farbe: |
Kunde spezifiziert |
OEM-Produkte: |
Annahme |
Transportpaket: |
Schlagzeug |
Spezifikation: |
CAAI-Kabel mit vollständigem Leiter |
Handelsmarke: |
UME |
Ursprung: |
China |
Hs-Code: |
8544492100 |
Versorgungsmaterial-Fähigkeit: |
500, 000 km pro Monat |
Typ: |
Isoliert |
Typ des Leiters: |
Massivstrang |
Anwendung: |
Unkosten |
Leitermaterial: |
Aluminium |
Gehäusematerial: |
mit einer Breite von nicht mehr als 15 mm |
Isoliermaterial: |
xlpe |
Proben: |
US$ 1/Stück 1 Stück ((Min.Bestellung) |
Ein-STOP-Lösungen für Kabel - HENAN UME CABLE CO., LTD
Über 30 Jahre Erfahrung in der Herstellung von Drähten und Kabeln und Export in über 50 Länder.
1. Anwendungen
2. Standard
CAAI-Kabelphasenleiter
CAAI-Kabel-neutrale Leiter
CAAI Kabelstraßenbeleuchtung Leiter
CAAI-Kabel-Komplettkabel
Fertiggestelltes Kabel | |||||
Größe | Ungefähr. | Ungefähr. Gewicht | Größe | Ungefähr. | Ungefähr. Gewicht |
mm2 | mm | in kg/km | mm2 | mm | in kg/km |
1x16 | 7.08 | 63.4 | 1x16+16+ND25 | 14.83 | 196.2 |
1x25 | 8.28 | 91.8 | 1x16+16+NA25 | 16.47 | 222.7 |
1x35 | 9.28 | 120.6 | 2x16+16+ND25 | 16.73 | 259.6 |
1x50 | 11.04 | 168.6 | 2x25+16+ND25 | 18.18 | 316.4 |
1x70 | 13.04 | 235.5 | 2x16+16+NA25 | 18.12 | 286 |
1x95 | 14.64 | 321.8 | 2x25+16+NA25 | 19.56 | 342.8 |
1x120 | 17.06 | 413.9 | 2x35+16+NA25 | 20.77 | 400.5 |
1x150 | 18.46 | 490.7 | 3x16+NA25 | 16.68 | 284.9 |
2x16 | 14.16 | 126.7 | 3x25+NA25 | 20.22 | 370.1 |
2x25 | 16.56 | 183.5 | 3x16+16+ND25 | 18.79 | 322.9 |
2x35 | 18.56 | 241.1 | 3x16+16+NA25 | 20.02 | 349.4 |
3x16 | 15.25 | 190.1 | 3x25+16+NA25 | 21.97 | 434.6 |
3x25 | 17.83 | 275.3 | 3x25+2x16+NA25 | 23.93 | 499.1 |
3x35 | 19.98 | 361.7 | 2x35+ND25 | 17.92 | 309.5 |
3x50 | 23.78 | 505.7 | 2x35+NA25 | 19.55 | 336 |
3x70 | 28.08 | 706.5 | 3x35+NA25 | 22.04 | 456.5 |
4x16 | 17.09 | 253.4 | 3x35+16+ND25 | 22.36 | 494.6 |
4x25 | 19.98 | 367.1 | 3x35+16+NA25 | 23.59 | 521 |
1x16+ND25 | 13.47 | 131.8 | 3x35+2x16+NA25 | 25.44 | 585.5 |
1x16+NA25 | 15.75 | 158.2 | 3x50+NA35 | 25.93 | 631.9 |
1x25+NA25 | 16.95 | 186.6 | 3x50+16+NA25 | 26.38 | 663.8 |
2x16+ND25 | 14.75 | 195.1 | 3x50+16+NA35 | 27.07 | 696.4 |
2x16+NA25 | 16.39 | 221.5 | 3x50+25+NA35 | 27.77 | 724.7 |
2x25+ND25 | 16.47 | 251.9 | 3x70+NA35 | 29.55 | 832.8 |
2x25+16 | 16.97 | 246.9 | 3x70+16+NA50 | 31.53 | 957.5 |
2x35+16 | 18.48 | 305.7 | 3x70+25+NA50 | 32.24 | 985.8 |
3x25+16 | 19.32 | 339.8 | 3x95+16+NA50 | 34.13 | 1188.3 |
3x35+16 | 21.13 | 426.2 | 3x95+NA50 | 33.81 | 1124.9 |
3x120+16 | 36.75 | 1306.3 | 3x95+16+NA70 | 35.02 | 1252.1 |
2x25+NA25 | 18.12 | 278.4 | 3x120+16+NA70 | 38.94 | 1555.5 |
Phasenleiter (Aluminiumleiter) | |||||||
Größe | Konstruktion des Leiters | XLPE-Dämmung | Ungefähr. | Max. Gleichstromwiderstand | |||
Nummer des Drahtes | D. von Draht | Das ist Dirigent Dia. | Nenndicke | Isolationsdia. | Gewicht | bei 20°C des Leiters | |
mm2 | - Nein. Ich weiß nicht. | mm | mm | mm | mm | in kg/km | Ohm/km |
16 | 7 | 1.72 | 4.8 | 1.14 | 7.08 | 63.35 | 1.91 |
25 | 7 | 2.18 | 6 | 1.14 | 8.28 | 91.75 | 1.2 |
35 | 7 | 2.55 | 7 | 1.14 | 9.28 | 120.56 | 0.868 |
50 | 7 | 2.97 | 8 | 1.52 | 11.04 | 168.55 | 0.641 |
70 | 19 | 2.2 | 10 | 1.52 | 13.04 | 235.51 | 0.443 |
95 | 19 | 2.58 | 11.6 | 1.52 | 14.64 | 312.79 | 0.32 |
120 | 19 | 2.88 | 13 | 2.03 | 17.06 | 413.94 | 0.253 |
Phasenleiter (Aluminiumleiter) | |||||||
Größe | Konstruktion des Leiters | XLPE-Dämmung | Ungefähr. | Max. Gleichstromwiderstand | |||
Nummer des Drahtes | D. von Draht | Das ist Dirigent Dia. | Nenndicke | Isolationsdia. | Gewicht | bei 20°C des Leiters | |
mm2 | - Nein. Ich weiß nicht. | mm | mm | mm | mm | in kg/km | Ohm/km |
16 | 7 | 1.72 | 4.8 | 1.14 | 7.08 | 63.35 | 1.91 |
25 | 7 | 2.18 | 6 | 1.14 | 8.28 | 91.75 | 1.2 |
35 | 7 | 2.55 | 7 | 1.14 | 9.28 | 120.56 | 0.868 |
50 | 7 | 2.97 | 8 | 1.52 | 11.04 | 168.55 | 0.641 |
70 | 19 | 2.2 | 10 | 1.52 | 13.04 | 235.51 | 0.443 |
95 | 19 | 2.58 | 11.6 | 1.52 | 14.64 | 312.79 | 0.32 |
120 | 19 | 2.88 | 13 | 2.03 | 17.06 | 413.94 | 0.253 |
Straßenbeleuchtung Leiter (Aluminiumleiter) | |||||||
Größe | Konstruktion des Leiters | XLPE-Dämmung | Ungefähr. | Max. Gleichstromwiderstand | |||
Nummer des Drahtes | D. von Draht | Das ist Dirigent Dia. | Nenndicke | Isolationsdia. | Gewicht | bei 20°C des Leiters | |
mm2 | - Nein. Ich weiß nicht. | mm | mm | mm | mm | in kg/km | Ohm/km |
16 | 7 | 1.72 | 4.8 | 1.14 | 7.08 | 63.35 | 1.91 |
25 | 7 | 2.18 | 6 | 1.14 | 8.28 | 91.75 | 1.2 |
HENAN UME CABLE CO., LTD hat eine strenge Qualitätskontrollpolitik in jedem Schritt von der Bestellung bis zum Kundendienst!
Produktion:
F1: Sind Sie Hersteller?
Ja, wir sind der Hersteller.
Q2: Was sind Ihre wichtigsten Produkte?
Unsere Produkte sind wie folgt:
1. Elektroleitungen/PVC-Gebäudeleitungen.
2. PVC/XLPE isolierte Stromkabel bis zu 110kv.
3- Oberflächliche Kabel/ABC-Kabel.
4. Barre Leiter, wie AAC, AAAC, ACSR, ACAR, ASCR/AW, und so weiter.
5. Stahldraht/strangartige EHS, GSW und ACS ((Aluminiumbeschichtete Stahl), CCS ((Kupferbeschichtete Stahl).
6Kabeln aus Gummi, Bergbaukabel, Schweißkabel und Steuerkabel.
7- Konzentrische Kabel mit Kupfer/Aluminium/Aluminiumlegierung 8000-Leiter.
Q3: Liefern Sie Proben? Ist es kostenlos oder extra?
Ja, wir können die Proben kostenlos anbieten.
Q4: Ist die Qualität Ihrer Produkte garantiert?
Wir haben ISO9001, ISO14001, ISO45001 bestanden und alle unsere Produkte haben CE-Zertifikate.
F5: In welchen Märkten sind Sie hauptsächlich tätig?
Unsere Produkte wurden hauptsächlich nach Afrika, dem Nahen Osten, Südostasien, Südamerika, Zentralamerika, Nordamerika, Europa, Australien usw. exportiert.
F6: Wie lautet Ihre Zahlungsfrist?
T/T oder L/C
F7: Was ist mit der Lieferzeit?
Im Allgemeinen sind es 3-7 Tage, wenn die Waren auf Lager sind. Oder es sind 7-30 Tage, wenn die Waren nicht auf Lager sind, es ist nach Menge.
